Model |
WG60 |
WG60G |
Measurement Range |
0-200Gu |
0-2000Gu |
Application |
Apply on paint, ink, stoving varnish, coating, wood products; Marble, granite, vitrified polished tile, pottery brick and porcelain; Plastic, paper; Other nonmetallic material. |
Apply on paint, ink, stoving varnish, coating, wood products; Marble, granite, vitrified polished tile, pottery brick and porcelain; Plastic, paper; Other nonmetallic material. |
Instrument Dimensions |
122x34x60mm |
122x34x60mm |
Projection Angle |
60° |
60° |
Measuring Spot |
(ellipse: long axis*minor axis) 8mm*4mm |
(ellipse: long axis*minor axis) 1mm*3mm |
Measuring Mode |
Automatic measurement/ manual measurement/ single measurement/average measurement and cross measurement for a variety of combination measuring mode |
Automatic measurement/ manual measurement/ single measurement/average measurement and cross measurement for a variety of combination measuring mode |
Data Storage |
100 groups |
500 groups |
Set standard sample in any stored data, user-define the tolerance range |
Set standard sample in any stored data, user-define the tolerance range |
Language |
Chinese/English |
Chinese/English |
Output |
Connect the micro printer to realize real-time output of measured data |
Connect the micro printer to realize real-time output of measured data |
Division Value |
0.1Gu |
0.1Gu |
Repeatability |
0.2Gu |
0.2Gu |
Reproducibility |
0.4Gu |
0.4Gu |
Indication Error |
1.0Gu |
1.0Gu |
International Standard 60° |
ISO 2813 , ASTM C584 , ASTM D523 , DIN 67530 , ASTM D2457 , JND-A60 and JND-P60 |
ISO 2813 , ASTM C584 , ASTM D523 , DIN 67530 , ASTM D2457 , JND-A60 and JND-P60 |
National Standard 60° |
GB 9754 , GB 9966 , GB 8807 |
GB 9754 , GB 9966 , GB 8807 |
Standard Accessories |
Power adapter/user manual/warranty certification/ standard board |
Power adapter/user manual/warranty certification/ standard board |
Optional Accessories |
Micro-printer |
Micro-printer |
